YOLO + Supervision + 额外识别 + 人员标记 人脸比对

目标:
用 YOLO 做物品 / 人员检测,用 supervision 做追踪、标记、画框、视频流处理,再根据需要接入额外识别模型,最后把识别结果保存到数据库。


1. 这份文档解决什么问题

你现在的需求大概可以拆成几个部分:

1
2
3
4
5
6
1. YOLO 训练出来的标记怎么显示到画面上?
2. YOLO 检测出来一个框之后,怎么继续接一个额外模型做识别?
3. 怎么把画面里的目标标记成 学生1、学生2、学生3?
4. 怎么把识别结果保存下来?
5. 如果后面真的要做人脸比对,代码应该怎么接?
6. 摄像头、RTSP、本地视频怎么传进去?

这份文档给你一个完整方案:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
摄像头 / RTSP / 本地视频

YOLO 主模型检测

supervision.Detections

置信度 / 类别过滤

ByteTrack 临时追踪

显示:学生1、学生2、学生3

可选:额外模型识别

可选:人脸 embedding 比对

画框 / 标签 / 轨迹

SQLite 保存事件

2. 先理解几个核心概念

2.1 YOLO 的标记是什么

YOLO 训练出来以后,输出的是检测框和类别。

例如你训练了一个教室场景模型,类别可能是:

1
2
3
4
5
6
7
8
person
student
teacher
phone
book
bag
desk
chair

YOLO 每一帧会输出:

1
2
3
4
框坐标 xyxy
类别 class_id
类别名称 class_name
置信度 confidence

例如:

1
2
3
person 0.86 [100, 80, 240, 420]
book 0.74 [300, 200, 380, 260]
phone 0.69 [450, 280, 500, 330]

这里的 personbookphone 就是 YOLO 训练出来的标记。


2.2 ByteTrack 的 tracker_id 是什么

ByteTrack 不是识别“这个人是谁”。

它只是判断连续视频帧中:

1
2
3
这一帧的这个框
和下一帧的那个框
大概率是同一个目标

所以它会生成类似:

1
2
3
tracker_id = 1
tracker_id = 2
tracker_id = 3

你可以把它显示成:

1
2
3
学生1
学生2
学生3

但是要注意:

1
2
3
ByteTrack 的 ID 是当前视频流里的临时 ID。
程序重启后,ID 可能重新分配。
今天的 学生1 不一定是明天的 学生1。

2.3 额外识别模型是什么

有时候一个 YOLO 模型只负责“先把目标找出来”。

例如:

1
2
3
4
5
6
7
8
9
10
11
主 YOLO 模型:
检测 person

额外识别模型:
判断这个 person crop 是:
学生
老师
穿校服
未穿校服
戴工牌
未戴工牌

流程是:

1
2
3
4
5
6
7
YOLO 检测 person 框

从原图裁剪 person 区域

把裁剪图传给额外模型

额外模型输出分类结果

例如最后画面显示:

1
2
学生1 | person 0.86 | uniform 0.93
学生2 | person 0.81 | no_uniform 0.88

2.4 人脸比对是什么

如果你想让系统跨多节课知道:

1
2
3
今天这个人是 student_001
明天这个人还是 student_001
下周这个人还是 student_001

那必须有某种稳定身份依据。

可以是:

1
2
3
4
5
6
扫码
刷卡
固定座位
老师手动确认
人脸 embedding
人体 ReID

如果使用人脸 embedding,即使不保存照片,也仍然属于人脸特征信息。

所以:

1
2
不保存照片 ≠ 没有处理人脸信息
只保存 embedding ≠ 完全匿名

如果你要做学校 / 教室 / 学生场景,建议优先考虑:

1
2
3
4
固定座位
二维码签到
老师确认
学生卡 / NFC

人脸识别只作为可选方案,而且要有明确授权和替代方式。


3. 推荐的三种方案

方案 A:只做本节课内临时编号

适合:

1
2
3
4
实时看画面
统计当前教室有几个人
看每个人在画面里的停留时间
不跨天识别具体是谁

技术:

1
2
YOLO person 检测
+ supervision ByteTrack

显示:

1
2
学生1 | person 0.86
学生2 | person 0.79

优点:

1
2
3
不需要人脸识别
不保存人脸信息
实现简单

缺点:

1
不能长期累计“某个学生来了多少次课”

方案 B:固定座位 / 老师绑定

适合:

1
2
教室座位比较固定
或者每节课开始老师确认一下谁是谁

技术:

1
2
3
4
YOLO person 检测
+ PolygonZone 座位区域判断
+ ByteTrack 本节课内追踪
+ SQLite 保存考勤

保存:

1
2
seat_01 / student_01 到课
seat_02 / student_02 到课

优点:

1
2
可以不做人脸识别
也可以统计长期次数

缺点:

1
2
学生换座位会出错
需要规则或人工确认

方案 C:人脸 embedding 比对

适合:

1
2
确实需要跨天自动识别同一个人
并且已经解决授权、合规、替代方案、数据删除机制

技术:

1
2
3
4
5
6
YOLO 检测 person
+ 裁剪 person 区域
+ InsightFace 检测人脸
+ 提取 embedding
+ SQLite 保存 embedding
+ 余弦相似度比对

优点:

1
可以跨多节课识别同一个人

缺点:

1
2
3
涉及生物识别信息
需要合规和授权
误识别要人工兜底

4. 项目初始化

使用 uv

1
2
3
4
5
mkdir edge-yolo-supervision-demo
cd edge-yolo-supervision-demo

uv init
uv add ultralytics supervision opencv-python numpy

如果需要人脸比对:

1
uv add insightface onnxruntime

如果你只做 YOLO + ByteTrack,不需要安装 insightface


5. 文件结构建议

1
2
3
4
5
6
7
edge-yolo-supervision-demo/
├── main.py
├── best.pt
├── extra_classifier.pt
├── events.sqlite3
├── face_identities.sqlite3
└── result.mp4

说明:

1
2
3
4
5
6
main.py                  主代码
best.pt 你训练好的 YOLO 主模型
extra_classifier.pt 可选,额外识别模型
events.sqlite3 保存检测事件
face_identities.sqlite3 可选,保存人脸 embedding
result.mp4 可选,保存标注后视频

6. 最小运行命令

6.1 摄像头 + 临时学生编号

1
2
3
4
uv run python main.py \
--source 0 \
--model yolov8n.pt \
--identity-mode track

6.2 使用你自己的 YOLO 模型

1
2
3
4
uv run python main.py \
--source 0 \
--model best.pt \
--identity-mode track

6.3 RTSP 摄像头

1
2
3
4
uv run python main.py \
--source rtsp://username:password@192.168.1.100:554/stream1 \
--model best.pt \
--identity-mode track

6.4 本地视频

1
2
3
4
uv run python main.py \
--source source.mp4 \
--model best.pt \
--output result.mp4

6.5 接额外识别模型

1
2
3
4
uv run python main.py \
--source 0 \
--model person_detector.pt \
--extra-model uniform_classifier.pt

6.6 启用人脸比对模式

1
2
3
4
5
uv run python main.py \
--source 0 \
--model yolov8n.pt \
--identity-mode face \
--face-db face_identities.sqlite3

7. YOLO 标记怎么显示到画面上

核心代码:

1
2
result = model(frame, verbose=False)[0]
detections = sv.Detections.from_ultralytics(result)

detections 里有:

1
2
3
detections.xyxy
detections.class_id
detections.confidence

然后根据 class_id 取名字:

1
class_name = model.names[int(class_id)]

拼标签:

1
label = f"{class_name} {confidence:.2f}"

最终显示:

1
2
3
person 0.86
book 0.74
phone 0.69

8. 怎么加上“学生1、学生2、学生3”

先通过 ByteTrack 生成 tracker_id

1
2
3
tracker = sv.ByteTrack()

detections = tracker.update_with_detections(detections)

然后:

1
2
tracker_id = detections.tracker_id[i]
display_id = f"学生{tracker_id}"

拼标签:

1
label = f"{display_id} | {class_name} {confidence:.2f}"

显示效果:

1
2
学生1 | person 0.86
学生2 | person 0.79

9. 额外识别模型怎么接

9.1 为什么要接额外模型

有时候主 YOLO 只负责“找目标”,额外模型负责“细分判断”。

例如:

1
2
3
4
5
主模型:
person 检测

额外模型:
判断是否穿校服

流程:

1
2
3
4
5
6
7
8
9
frame

YOLO 检测 person

裁剪 person 框

extra_model(crop)

输出 uniform / no_uniform

9.2 裁剪检测框

1
2
3
4
5
6
7
8
9
10
11
12
13
def crop_xyxy(frame, xyxy):
h, w = frame.shape[:2]
x1, y1, x2, y2 = xyxy.astype(int).tolist()

x1 = max(0, min(x1, w - 1))
y1 = max(0, min(y1, h - 1))
x2 = max(0, min(x2, w))
y2 = max(0, min(y2, h))

if x2 <= x1 or y2 <= y1:
return None

return frame[y1:y2, x1:x2].copy()

9.3 把 crop 传给额外模型

1
extra_result = extra_model(crop, verbose=False)[0]

如果额外模型是分类模型:

1
2
3
top1 = int(extra_result.probs.top1)
conf = float(extra_result.probs.top1conf)
label = extra_model.names[top1]

如果额外模型还是检测模型:

1
2
3
4
5
boxes = extra_result.boxes
best_index = int(np.argmax(boxes.conf.cpu().numpy()))
class_id = int(boxes.cls[best_index].cpu().item())
conf = float(boxes.conf[best_index].cpu().item())
label = extra_model.names[class_id]

最后显示:

1
学生1 | person 0.86 | uniform 0.93

10. 怎么保存识别结果

示例里用 SQLite 保存。

事件表字段:

1
2
3
4
5
6
7
8
9
10
11
ts              时间戳
frame_index 第几帧
tracker_id ByteTrack 临时 ID
display_id 显示 ID,例如 学生1
yolo_class YOLO 类别
yolo_conf YOLO 置信度
xyxy_json 检测框坐标
extra_label 额外识别结果
extra_conf 额外识别置信度
face_id 可选,人脸 ID
face_score 可选,人脸相似度

插入事件:

1
2
3
4
5
6
7
8
9
10
11
12
store.insert_event(
frame_index=frame_index,
tracker_id=tracker_id,
display_id=display_id,
yolo_class=yolo_class,
yolo_conf=yolo_conf,
xyxy=xyxy,
extra_label=extra_label,
extra_conf=extra_conf,
face_id=face_id,
face_score=face_score,
)

不建议每一帧都保存。

建议:

1
2
同一个目标每 3 秒 / 5 秒保存一次
或者只在进入区域 / 越线 / 识别变化时保存

11. 人脸比对怎么做

11.1 人脸比对流程

1
2
3
4
5
6
7
8
9
10
11
12
13
YOLO 检测 person

裁剪 person 区域

InsightFace 检测人脸

提取 embedding

和数据库里已有 embedding 做余弦相似度

如果相似度大于阈值,认为是同一个人

如果没有匹配到,创建新 face_id

11.2 embedding 比对

1
score = np.dot(current_embedding, saved_embedding)

一般会先归一化:

1
embedding = embedding / np.linalg.norm(embedding)

阈值不是固定的,需要你用自己的数据测试。

1
2
阈值太低:不同人容易被认成同一个
阈值太高:同一个人可能匹配不上

示例里默认:

1
face_threshold = 0.45

但真实项目一定要自己测试。


12. 摄像头 / RTSP / 视频怎么传入

代码统一使用 OpenCV:

1
cap = cv2.VideoCapture(source)

如果是本地摄像头:

1
source = 0

如果是 RTSP:

1
source = "rtsp://username:password@192.168.1.100:554/stream1"

如果是本地视频:

1
source = "source.mp4"

读取帧:

1
2
3
4
5
6
while True:
ret, frame = cap.read()
if not ret:
break

annotated, detections, labels = process_frame(frame)

13. 最终画面标签格式

示例代码里最终标签可能是:

1
2
3
学生1 | person 0.86
学生2 | person 0.78 | uniform 0.91
face_001 | person 0.83 | face_score 0.67

含义:

1
2
3
4
5
学生1             ByteTrack 临时编号
person 0.86 YOLO 主模型检测结果
uniform 0.91 额外识别模型结果
face_001 人脸 embedding 匹配结果
face_score 0.67 人脸相似度

14. 推荐你先跑哪个模式

建议先按顺序来:

1
2
3
4
5
6
第一步:yolov8n.pt + 摄像头跑通
第二步:best.pt + 摄像头跑通
第三步:打开 ByteTrack 临时编号
第四步:保存 SQLite 事件
第五步:接额外识别模型
第六步:确认合规后再考虑人脸模式

最推荐先跑:

1
2
3
4
uv run python main.py \
--source 0 \
--model yolov8n.pt \
--identity-mode track

15. 完整代码

下面这份代码可以直接保存为:

1
main.py

然后运行。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
577
578
579
580
581
582
583
584
585
586
587
588
589
590
591
592
593
594
595
596
597
598
599
600
601
602
603
604
605
606
607
608
609
610
611
612
613
614
615
616
617
618
619
620
621
622
623
624
625
626
627
628
629
630
631
632
633
634
635
636
637
638
639
640
641
642
643
644
645
646
647
648
649
650
651
652
653
654
655
656
657
658
659
660
661
662
663
664
665
666
667
668
669
670
671
672
673
674
675
676
677
678
679
680
681
682
683
684
685
686
687
688
689
690
691
692
693
694
695
696
697
698
699
700
701
702
703
704
705
706
707
708
709
710
711
712
713
714
715
716
717
718
719
720
721
722
723
724
725
726
727
728
729
730
731
732
733
734
735
736
737
738
739
740
741
742
743
744
745
746
747
748
749
750
751
752
753
754
755
756
757
758
759
760
761
762
763
764
765
766
767
768
769
770
771
772
773
774
775
776
777
778
779
780
781
782
783
784
785
786
787
788
789
790
791
792
793
794
795
796
797
798
799
800
801
802
803
804
805
806
807
808
809
810
811
812
813
814
815
816
817
818
819
820
821
822
823
824
825
826
827
828
829
830
831
832
833
834
835
836
837
838
839
840
841
842
843
844
845
846
847
848
849
850
851
852
853
854
855
856
857
858
859
860
861
862
863
864
865
866
867
868
869
870
871
872
873
874
875
876
877
878
879
880
881
882
883
884
885
886
887
888
889
890
891
892
893
894
895
896
897
898
899
900
901
902
903
904
905
906
907
908
909
910
911
912
913
914
915
916
917
918
919
920
921
922
923
924
925
926
927
928
929
930
931
932
933
934
935
936
937
938
939
940
941
942
943
944
945
946
947
948
949
950
951
952
953
954
955
956
957
958
959
960
961
962
963
964
965
966
967
968
969
970
971
972
973
974
975
976
977
978
979
980
981
982
983
984
985
986
987
988
989
990
991
992
993
994
995
996
997
998
999
1000
1001
1002
1003
1004
1005
1006
1007
1008
1009
1010
1011
1012
1013
1014
1015
1016
1017
1018
1019
1020
1021
1022
1023
1024
1025
1026
1027
1028
1029
1030
1031
1032
1033
1034
1035
1036
1037
1038
1039
1040
1041
1042
1043
1044
1045
1046
1047
1048
1049
1050
1051
1052
1053
1054
1055
1056
1057
1058
1059
1060
1061
1062
1063
1064
1065
1066
1067
1068
1069
1070
1071
1072
1073
1074
1075
1076
1077
1078
1079
1080
1081
1082
1083
1084
1085
1086
1087
1088
1089
1090
1091
1092
1093
1094
1095
1096
1097
1098
1099
1100
1101
1102
1103
1104
1105
1106
1107
1108
1109
1110
1111
1112
1113
1114
1115
1116
1117
1118
1119
1120
1121
1122
1123
1124
1125
1126
1127
1128
1129
1130
1131
1132
1133
1134
1135
1136
1137
1138
#!/usr/bin/env python3
# -*- coding: utf-8 -*-

"""
edge_yolo_label_extra_face_demo.py

用途:
这是一个“YOLO 标记 + supervision 追踪 + 额外识别模型 + 可选人脸/人员比对 + SQLite 保存结果”的完整示例。

你可以把它用于学习下面几个问题:

1. YOLO 训练出来的标记怎么加到画面上?
例如:person、cup、helmet、phone、你的自定义商品类别等。

2. YOLO 检测框出来后,怎么再接一个额外识别模型?
例如:
- YOLO 先检测 person
- 再裁剪 person 区域
- 把裁剪图交给另一个分类模型判断:学生 / 老师 / 是否穿校服 / 是否戴安全帽

3. 怎么把 ByteTrack 的临时追踪 ID 显示成“学生1、学生2、学生3”?
注意:这是本次程序运行内的临时编号,不是长期身份识别。

4. 如果确实需要跨多节课识别“是不是同一个人”,人脸比对应该怎么接?
这个文件提供了可选 face 模式。
但要注意:人脸 embedding 也属于生物识别信息。
即使不保存照片,只保存向量,也不是“完全不采集人脸信息”。
实际项目里需要明确告知、授权、最小化采集、本地加密、设置删除期限,并提供非人脸替代方式。

默认模式:
默认使用 identity-mode=track:
- 不做人脸识别
- 不保存人脸图像
- 只用 ByteTrack 给当前视频流里的目标分配临时 ID
- 显示:学生1、学生2、学生3

可选 face 模式:
使用 identity-mode=face:
- 会启用 InsightFace 提取人脸 embedding
- 会把 embedding 存入 SQLite,用于下次比对
- 不会默认保存人脸图片
- 这是生物识别处理,需要你自己确保合规和授权

安装:

uv init
uv add ultralytics supervision opencv-python numpy

如果你要启用人脸比对:

uv add insightface onnxruntime

如果是 NVIDIA GPU 并且你知道环境支持,也可以自己改为 onnxruntime-gpu。

运行示例:

1. 摄像头 + YOLO + 临时学生编号

uv run python edge_yolo_label_extra_face_demo.py \
--source 0 \
--model yolov8n.pt \
--identity-mode track

2. 摄像头 + 自己训练的 YOLO

uv run python edge_yolo_label_extra_face_demo.py \
--source 0 \
--model best.pt \
--identity-mode track

3. RTSP 摄像头

uv run python edge_yolo_label_extra_face_demo.py \
--source rtsp://username:password@192.168.1.100:554/stream1 \
--model best.pt

4. 本地视频

uv run python edge_yolo_label_extra_face_demo.py \
--source source.mp4 \
--model best.pt \
--output result.mp4

5. YOLO 检测 + 额外分类模型

uv run python edge_yolo_label_extra_face_demo.py \
--source 0 \
--model person_detector.pt \
--extra-model uniform_classifier.pt

6. 人脸比对模式,不保存人脸图片,只保存 embedding

uv run python edge_yolo_label_extra_face_demo.py \
--source 0 \
--model yolov8n.pt \
--identity-mode face \
--face-db face_identities.sqlite3

整体流程:

视频帧 frame

YOLO 主模型检测

sv.Detections.from_ultralytics(result)

过滤置信度 / 类别

ByteTrack 追踪,得到 tracker_id

对每个检测框裁剪 crop

可选:额外模型识别 crop

可选:人脸模型提取 embedding 并比对

拼接显示标签

画框、显示、保存事件到 SQLite

重要概念:

YOLO 的 class_id / class_name 是“类别标记”:
person、cup、helmet、student、teacher、phone、product_A

ByteTrack 的 tracker_id 是“视频内临时编号”:
当前这次运行里,某个目标可能是 #1、#2、#3

Face embedding 的 face_id 是“跨运行身份编号”:
如果启用人脸比对,系统可能会把某个人记为 face_001

这三者不是同一个东西:

class_name 代表“这是什么”
tracker_id 代表“这个目标在当前视频里是谁”
face_id 代表“这个人是否和数据库里的某个 face_id 匹配”

推荐学习顺序:

第一步:只跑 --identity-mode track
第二步:接你自己的 best.pt
第三步:接 --extra-model 做二次识别
第四步:确认确实需要并合规后,再考虑 --identity-mode face
"""

import argparse
import json
import sqlite3
import time
from dataclasses import dataclass
from pathlib import Path
from typing import Optional, Tuple, List, Dict, Any

import cv2
import numpy as np
import supervision as sv
from ultralytics import YOLO


# =========================
# 1. 工具函数
# =========================

def parse_source(source: str):
"""
OpenCV 的 VideoCapture 支持:
0 本机摄像头
source.mp4 本地视频
rtsp://... RTSP 流

argparse 读进来的都是字符串。
如果用户传入 "0",这里转成 int 0。
"""
if source.isdigit():
return int(source)
return source


def safe_float(value) -> float:
"""
Ultralytics / PyTorch / NumPy 里有些数值是 tensor 或 ndarray。
这个函数统一转成 Python float。
"""
try:
if hasattr(value, "detach"):
value = value.detach()
if hasattr(value, "cpu"):
value = value.cpu()
if hasattr(value, "item"):
return float(value.item())
return float(value)
except Exception:
return 0.0


def normalize_vector(vec: np.ndarray) -> np.ndarray:
"""
把向量归一化,便于余弦相似度计算。
"""
vec = np.asarray(vec, dtype=np.float32)
norm = np.linalg.norm(vec)
if norm <= 1e-12:
return vec
return vec / norm


def crop_xyxy(frame: np.ndarray, xyxy: np.ndarray) -> Optional[np.ndarray]:
"""
根据 [x1, y1, x2, y2] 从原图裁剪目标区域。
"""
h, w = frame.shape[:2]

x1, y1, x2, y2 = xyxy.astype(int).tolist()

x1 = max(0, min(x1, w - 1))
y1 = max(0, min(y1, h - 1))
x2 = max(0, min(x2, w))
y2 = max(0, min(y2, h))

if x2 <= x1 or y2 <= y1:
return None

return frame[y1:y2, x1:x2].copy()


def get_model_name(model: YOLO, class_id: int) -> str:
"""
从 Ultralytics 模型里根据 class_id 取 class_name。
"""
names = model.names

if isinstance(names, dict):
return str(names.get(class_id, f"class_{class_id}"))

if isinstance(names, list) and 0 <= class_id < len(names):
return str(names[class_id])

return f"class_{class_id}"


def make_box_annotator():
"""
supervision 版本之间命名有过变化:
较新版本推荐 BoxAnnotator
一些版本里也有 BoundingBoxAnnotator

这里做兼容。
"""
if hasattr(sv, "BoxAnnotator"):
return sv.BoxAnnotator()
return sv.BoundingBoxAnnotator()


# =========================
# 2. SQLite 保存
# =========================

class EventStore:
"""
保存检测事件。

默认保存字段:
- 时间
- 帧号
- tracker_id
- YOLO 类别和置信度
- 检测框
- 额外模型识别结果
- face_id / face_score,如果启用了人脸模式

注意:
为了避免每一帧都写数据库,主循环里会做保存间隔控制。
"""

def __init__(self, db_path: str):
self.db_path = db_path
self.conn = sqlite3.connect(db_path)
self.init_tables()

def init_tables(self):
self.conn.execute(
"""
CREATE TABLE IF NOT EXISTS events (
id INTEGER PRIMARY KEY AUTOINCREMENT,
ts REAL NOT NULL,
frame_index INTEGER NOT NULL,
tracker_id INTEGER,
display_id TEXT,
yolo_class TEXT,
yolo_conf REAL,
xyxy_json TEXT,
extra_label TEXT,
extra_conf REAL,
face_id TEXT,
face_score REAL
)
"""
)
self.conn.commit()

def insert_event(
self,
frame_index: int,
tracker_id: Optional[int],
display_id: str,
yolo_class: str,
yolo_conf: float,
xyxy: np.ndarray,
extra_label: Optional[str],
extra_conf: Optional[float],
face_id: Optional[str],
face_score: Optional[float],
):
self.conn.execute(
"""
INSERT INTO events (
ts, frame_index, tracker_id, display_id,
yolo_class, yolo_conf, xyxy_json,
extra_label, extra_conf, face_id, face_score
)
VALUES (?, ?, ?, ?, ?, ?, ?, ?, ?, ?, ?)
""",
(
time.time(),
frame_index,
tracker_id,
display_id,
yolo_class,
yolo_conf,
json.dumps([float(x) for x in xyxy.tolist()], ensure_ascii=False),
extra_label,
extra_conf,
face_id,
face_score,
),
)
self.conn.commit()

def close(self):
self.conn.close()


# =========================
# 3. 人脸 embedding 存储和比对
# =========================

class FaceIdentityStore:
"""
保存 face embedding,用于跨运行比对。

重要提醒:
这里保存的是人脸 embedding,不是普通匿名信息。
它仍然可以用于识别同一个人。
实际项目里需要合规处理。

数据表:
face_id 例如 face_001
embedding float32 向量的二进制
dim 向量维度
created_at 创建时间
"""

def __init__(self, db_path: str):
self.db_path = db_path
self.conn = sqlite3.connect(db_path)
self.init_tables()

def init_tables(self):
self.conn.execute(
"""
CREATE TABLE IF NOT EXISTS face_identities (
face_id TEXT PRIMARY KEY,
embedding BLOB NOT NULL,
dim INTEGER NOT NULL,
created_at REAL NOT NULL
)
"""
)
self.conn.commit()

def _load_all(self) -> List[Tuple[str, np.ndarray]]:
rows = self.conn.execute(
"SELECT face_id, embedding, dim FROM face_identities"
).fetchall()

result = []
for face_id, blob, dim in rows:
emb = np.frombuffer(blob, dtype=np.float32, count=dim)
emb = normalize_vector(emb)
result.append((face_id, emb))

return result

def _next_face_id(self) -> str:
row = self.conn.execute(
"SELECT COUNT(*) FROM face_identities"
).fetchone()
count = int(row[0]) if row else 0
return f"face_{count + 1:03d}"

def create_identity(self, embedding: np.ndarray) -> str:
embedding = normalize_vector(embedding).astype(np.float32)
face_id = self._next_face_id()

self.conn.execute(
"""
INSERT INTO face_identities (face_id, embedding, dim, created_at)
VALUES (?, ?, ?, ?)
""",
(
face_id,
embedding.tobytes(),
int(embedding.shape[0]),
time.time(),
),
)
self.conn.commit()

return face_id

def find_or_create(
self,
embedding: np.ndarray,
threshold: float,
auto_create: bool = True,
) -> Tuple[Optional[str], float, bool]:
"""
用余弦相似度比对人脸 embedding。

返回:
face_id: 匹配到的 ID,或者新建的 ID
best_score: 相似度
created: 是否新建身份

threshold:
阈值需要你自己在真实场景里测试。
太低:容易把不同人认成同一个
太高:同一个人也可能匹配不上

常见做法:
先用测试集统计不同阈值下的误识别率和漏识别率,再决定。
"""
embedding = normalize_vector(embedding)

identities = self._load_all()

if not identities:
if auto_create:
return self.create_identity(embedding), 1.0, True
return None, 0.0, False

best_id = None
best_score = -1.0

for face_id, saved_embedding in identities:
score = float(np.dot(embedding, saved_embedding))
if score > best_score:
best_score = score
best_id = face_id

if best_score >= threshold:
return best_id, best_score, False

if auto_create:
return self.create_identity(embedding), best_score, True

return None, best_score, False

def close(self):
self.conn.close()


# =========================
# 4. 可选:InsightFace 人脸识别
# =========================

class FaceRecognizer:
"""
InsightFace 封装。

依赖安装:
uv add insightface onnxruntime

第一次使用时,InsightFace 可能会下载模型。

providers:
CPU:
["CPUExecutionProvider"]

GPU:
需要自己安装 onnxruntime-gpu,并确认 CUDA 环境可用。
"""

def __init__(self, use_gpu: bool = False):
try:
from insightface.app import FaceAnalysis
except Exception as e:
raise RuntimeError(
"未安装 insightface。请先执行:uv add insightface onnxruntime"
) from e

providers = ["CPUExecutionProvider"]

self.app = FaceAnalysis(
name="buffalo_l",
providers=providers,
)

# ctx_id=-1 表示 CPU
# ctx_id=0 通常表示第 0 张 GPU,但前提是环境支持
ctx_id = 0 if use_gpu else -1

self.app.prepare(
ctx_id=ctx_id,
det_size=(640, 640),
)

def extract_best_face_embedding(
self,
bgr_image: np.ndarray,
) -> Tuple[Optional[np.ndarray], Optional[np.ndarray]]:
"""
输入 BGR 图片,返回最大人脸的 embedding 和 face_bbox。

返回:
embedding: np.ndarray 或 None
face_bbox: [x1, y1, x2, y2],坐标是相对于 bgr_image 的
"""
faces = self.app.get(bgr_image)

if not faces:
return None, None

def face_area(face):
x1, y1, x2, y2 = face.bbox
return max(0, x2 - x1) * max(0, y2 - y1)

best_face = max(faces, key=face_area)

if hasattr(best_face, "normed_embedding") and best_face.normed_embedding is not None:
embedding = np.asarray(best_face.normed_embedding, dtype=np.float32)
else:
embedding = normalize_vector(np.asarray(best_face.embedding, dtype=np.float32))

bbox = np.asarray(best_face.bbox, dtype=np.float32)

return embedding, bbox


# =========================
# 5. 额外识别模型
# =========================

@dataclass
class ExtraRecognitionResult:
label: Optional[str]
confidence: Optional[float]


class ExtraRecognizer:
"""
额外识别模型封装。

支持两种常见情况:

情况 A:额外模型是分类模型
例如:
uniform_classifier.pt
phone_classifier.pt
student_teacher_classifier.pt

输入:主 YOLO 检测框裁剪出来的 crop
输出:top1 类别

情况 B:额外模型还是检测模型
例如:
主模型检测 person
额外模型在 person crop 里检测 face / badge / helmet / phone

输入:crop
输出:最高置信度的检测类别

说明:
这个类只是一个通用示例。
实际项目里你可以按自己的业务改成更精细的逻辑。
"""

def __init__(self, model_path: str):
self.model = YOLO(model_path)

def recognize(self, crop: np.ndarray) -> ExtraRecognitionResult:
if crop is None or crop.size == 0:
return ExtraRecognitionResult(label=None, confidence=None)

result = self.model(crop, verbose=False)[0]

# 分类模型:result.probs 不为空
if getattr(result, "probs", None) is not None:
top1 = int(result.probs.top1)
conf = safe_float(result.probs.top1conf)
label = get_model_name(self.model, top1)
return ExtraRecognitionResult(label=label, confidence=conf)

# 检测模型:result.boxes 不为空
boxes = getattr(result, "boxes", None)
if boxes is not None and len(boxes) > 0:
confs = boxes.conf
best_index = int(np.argmax(confs.cpu().numpy()))
class_id = int(boxes.cls[best_index].cpu().item())
conf = safe_float(boxes.conf[best_index])
label = get_model_name(self.model, class_id)
return ExtraRecognitionResult(label=label, confidence=conf)

return ExtraRecognitionResult(label=None, confidence=None)


# =========================
# 6. 主应用
# =========================

class App:
def __init__(self, args):
self.args = args

self.source = parse_source(args.source)
self.main_model = YOLO(args.model)

self.tracker = sv.ByteTrack()

if hasattr(sv, "DetectionsSmoother"):
self.smoother = sv.DetectionsSmoother()
else:
self.smoother = None

self.box_annotator = make_box_annotator()
self.label_annotator = sv.LabelAnnotator()

self.trace_annotator = sv.TraceAnnotator() if hasattr(sv, "TraceAnnotator") else None

self.event_store = EventStore(args.event_db)

self.extra_recognizer = None
if args.extra_model:
self.extra_recognizer = ExtraRecognizer(args.extra_model)

self.face_recognizer = None
self.face_store = None

if args.identity_mode == "face":
self.face_recognizer = FaceRecognizer(use_gpu=args.face_gpu)
self.face_store = FaceIdentityStore(args.face_db)

self.last_saved_at: Dict[str, float] = {}

def close(self):
self.event_store.close()
if self.face_store is not None:
self.face_store.close()

def filter_detections(self, detections: sv.Detections) -> sv.Detections:
"""
过滤检测结果:
- 置信度过滤
- 类别白名单过滤
"""
if len(detections) == 0:
return detections

detections = detections[detections.confidence >= self.args.conf]

if self.args.class_whitelist:
classes = [int(x.strip()) for x in self.args.class_whitelist.split(",") if x.strip()]
if len(classes) > 0 and len(detections) > 0:
detections = detections[np.isin(detections.class_id, classes)]

return detections

def get_display_id(
self,
tracker_id: Optional[int],
face_id: Optional[str],
) -> str:
"""
决定画面上显示什么 ID。

identity-mode=track:
显示:学生1、学生2、学生3
注意:这是临时编号。

identity-mode=face:
如果识别到 face_id,显示 face_001
如果没识别到,退回显示 tracker_id

identity-mode=none:
不显示学生编号,只显示类别。
"""
if self.args.identity_mode == "none":
return ""

if self.args.identity_mode == "face" and face_id:
return face_id

if tracker_id is not None:
return f"{self.args.label_prefix}{tracker_id}"

return f"{self.args.label_prefix}?"

def should_save_event(self, key: str) -> bool:
"""
控制保存频率。

不建议每一帧都写数据库。
默认每个目标每 save_interval 秒保存一次。
"""
now = time.time()
last = self.last_saved_at.get(key, 0)

if now - last >= self.args.save_interval:
self.last_saved_at[key] = now
return True

return False

def recognize_face_if_enabled(
self,
crop: Optional[np.ndarray],
) -> Tuple[Optional[str], Optional[float]]:
"""
如果启用了 face 模式,则对目标裁剪图做:
人脸检测
embedding 提取
和数据库比对
匹配不到则创建新 face_id

默认不保存人脸图片。
"""
if self.args.identity_mode != "face":
return None, None

if crop is None or crop.size == 0:
return None, None

if self.face_recognizer is None or self.face_store is None:
return None, None

embedding, face_bbox = self.face_recognizer.extract_best_face_embedding(crop)

if embedding is None:
return None, None

face_id, score, created = self.face_store.find_or_create(
embedding=embedding,
threshold=self.args.face_threshold,
auto_create=True,
)

# 默认不保存人脸图像。
# 只在你明确打开 --save-face-debug 时,为调试保存裁剪图。
if self.args.save_face_debug and face_bbox is not None and face_id:
self.save_debug_face_crop(crop, face_bbox, face_id)

return face_id, score

def save_debug_face_crop(
self,
person_crop: np.ndarray,
face_bbox: np.ndarray,
face_id: str,
):
"""
调试用:保存人脸裁剪图。

注意:
真实系统不建议默认保存人脸图片。
这个开关只适合本地开发调试,并且要有明确授权。
"""
out_dir = Path("debug_faces")
out_dir.mkdir(parents=True, exist_ok=True)

x1, y1, x2, y2 = face_bbox.astype(int).tolist()

h, w = person_crop.shape[:2]
x1 = max(0, min(x1, w - 1))
y1 = max(0, min(y1, h - 1))
x2 = max(0, min(x2, w))
y2 = max(0, min(y2, h))

if x2 <= x1 or y2 <= y1:
return

face_crop = person_crop[y1:y2, x1:x2].copy()
filename = out_dir / f"{face_id}_{int(time.time() * 1000)}.jpg"
cv2.imwrite(str(filename), face_crop)

def process_frame(
self,
frame: np.ndarray,
frame_index: int,
) -> Tuple[np.ndarray, sv.Detections, List[str]]:
"""
处理一帧:
1. 主 YOLO 检测
2. 转 supervision.Detections
3. 过滤
4. ByteTrack 追踪
5. 可选平滑
6. 每个框做额外模型识别 / 人脸比对
7. 拼标签
8. 画框
"""
result = self.main_model(frame, verbose=False)[0]

detections = sv.Detections.from_ultralytics(result)
detections = self.filter_detections(detections)

detections = self.tracker.update_with_detections(detections)

if self.smoother is not None and len(detections) > 0:
detections = self.smoother.update_with_detections(detections)

labels = []

for i in range(len(detections)):
xyxy = detections.xyxy[i]
class_id = int(detections.class_id[i])
yolo_conf = float(detections.confidence[i])
yolo_class = get_model_name(self.main_model, class_id)

tracker_id = None
if detections.tracker_id is not None:
raw_tracker_id = detections.tracker_id[i]
if raw_tracker_id is not None:
tracker_id = int(raw_tracker_id)

crop = crop_xyxy(frame, xyxy)

# 额外识别模型
extra_label = None
extra_conf = None

if self.extra_recognizer is not None and crop is not None:
extra_result = self.extra_recognizer.recognize(crop)
extra_label = extra_result.label
extra_conf = extra_result.confidence

# 人脸/人员比对
# 建议只在主 YOLO 类别是 person 时启用。
face_id = None
face_score = None

if self.args.identity_mode == "face" and yolo_class == self.args.face_target_class:
face_id, face_score = self.recognize_face_if_enabled(crop)

display_id = self.get_display_id(
tracker_id=tracker_id,
face_id=face_id,
)

# 拼接画面标签
label_parts = []

if display_id:
label_parts.append(display_id)

label_parts.append(f"{yolo_class} {yolo_conf:.2f}")

if extra_label:
if extra_conf is not None:
label_parts.append(f"{extra_label} {extra_conf:.2f}")
else:
label_parts.append(extra_label)

if face_id and face_score is not None:
label_parts.append(f"face_score {face_score:.2f}")

label = " | ".join(label_parts)
labels.append(label)

# 保存事件
# 使用 face_id 优先,其次 tracker_id,最后使用检测框索引
save_key = face_id or (f"track_{tracker_id}" if tracker_id is not None else f"det_{i}")

if self.should_save_event(save_key):
self.event_store.insert_event(
frame_index=frame_index,
tracker_id=tracker_id,
display_id=display_id,
yolo_class=yolo_class,
yolo_conf=yolo_conf,
xyxy=xyxy,
extra_label=extra_label,
extra_conf=extra_conf,
face_id=face_id,
face_score=face_score,
)

annotated = frame.copy()

if self.trace_annotator is not None and len(detections) > 0:
annotated = self.trace_annotator.annotate(
scene=annotated,
detections=detections,
)

annotated = self.box_annotator.annotate(
scene=annotated,
detections=detections,
)

annotated = self.label_annotator.annotate(
scene=annotated,
detections=detections,
labels=labels,
)

cv2.putText(
annotated,
f"frame: {frame_index}",
(20, 40),
cv2.FONT_HERSHEY_SIMPLEX,
1,
(0, 255, 0),
2,
)

return annotated, detections, labels

def run(self):
cap = cv2.VideoCapture(self.source)

if not cap.isOpened():
raise RuntimeError(f"无法打开视频源:{self.args.source}")

writer = None
frame_index = 0

try:
while True:
ret, frame = cap.read()

if not ret:
print("视频流结束或读取失败")
break

annotated, detections, labels = self.process_frame(
frame=frame,
frame_index=frame_index,
)

if writer is None and self.args.output:
h, w = annotated.shape[:2]
fps = cap.get(cv2.CAP_PROP_FPS)
if fps is None or fps <= 1:
fps = self.args.output_fps

fourcc = cv2.VideoWriter_fourcc(*"mp4v")
writer = cv2.VideoWriter(
self.args.output,
fourcc,
float(fps),
(w, h),
)

if writer is not None:
writer.write(annotated)

if not self.args.no_window:
cv2.imshow("YOLO + supervision + extra recognition", annotated)

if cv2.waitKey(1) & 0xFF == ord("q"):
break

frame_index += 1

finally:
cap.release()

if writer is not None:
writer.release()

if not self.args.no_window:
cv2.destroyAllWindows()

self.close()


# =========================
# 7. 命令行参数
# =========================

def build_arg_parser():
parser = argparse.ArgumentParser(
description="YOLO + supervision + 额外识别 + 可选人脸比对 示例"
)

parser.add_argument(
"--source",
default="0",
help="视频源:0 表示本机摄像头,也可以是 source.mp4 或 rtsp://...",
)

parser.add_argument(
"--model",
default="yolov8n.pt",
help="主 YOLO 模型路径,例如 yolov8n.pt 或 best.pt",
)

parser.add_argument(
"--extra-model",
default=None,
help="可选:额外识别模型路径,例如 uniform_classifier.pt;不传则不启用",
)

parser.add_argument(
"--conf",
type=float,
default=0.35,
help="主 YOLO 检测置信度阈值",
)

parser.add_argument(
"--class-whitelist",
default=None,
help="只保留指定 class_id,例如 '0' 或 '0,2,3';不传则不过滤类别",
)

parser.add_argument(
"--identity-mode",
choices=["none", "track", "face"],
default="track",
help=(
"none: 不显示身份编号;"
"track: 使用 ByteTrack 临时编号;"
"face: 使用人脸 embedding 比对,需要 insightface"
),
)

parser.add_argument(
"--label-prefix",
default="学生",
help="track 模式下的显示前缀,例如 学生、目标、person_",
)

parser.add_argument(
"--event-db",
default="events.sqlite3",
help="检测事件保存数据库",
)

parser.add_argument(
"--save-interval",
type=float,
default=5.0,
help="同一个目标每隔多少秒保存一次事件,避免每帧写数据库",
)

parser.add_argument(
"--output",
default=None,
help="可选:保存标注后的视频,例如 result.mp4",
)

parser.add_argument(
"--output-fps",
type=int,
default=25,
help="视频源读不到 FPS 时,输出视频使用的默认 FPS",
)

parser.add_argument(
"--no-window",
action="store_true",
help="不弹出窗口,适合服务器 / 边缘设备无桌面环境",
)

# face 模式相关
parser.add_argument(
"--face-db",
default="face_identities.sqlite3",
help="face 模式下保存人脸 embedding 的数据库",
)

parser.add_argument(
"--face-threshold",
type=float,
default=0.45,
help="face embedding 余弦相似度阈值,需要用你的场景数据测试调整",
)

parser.add_argument(
"--face-target-class",
default="person",
help="只有主 YOLO 类别等于这个名字时才做人脸比对,默认 person",
)

parser.add_argument(
"--face-gpu",
action="store_true",
help="尝试使用 GPU 跑 InsightFace,前提是你安装并配置了 onnxruntime-gpu",
)

parser.add_argument(
"--save-face-debug",
action="store_true",
help="调试用:保存人脸裁剪图到 debug_faces/。真实项目不建议默认开启。",
)

return parser


def main():
parser = build_arg_parser()
args = parser.parse_args()

print("=" * 80)
print("YOLO + supervision + 额外识别 + 可选人脸比对 示例")
print("=" * 80)
print(f"视频源: {args.source}")
print(f"主模型: {args.model}")
print(f"额外模型: {args.extra_model}")
print(f"identity-mode: {args.identity_mode}")
print(f"事件数据库: {args.event_db}")

if args.identity_mode == "face":
print()
print("注意:你启用了 face 模式。")
print("这会提取并保存人脸 embedding,用于跨运行比对。")
print("即使不保存照片,embedding 也属于可用于识别个人的生物识别信息。")
print("请确保已获得明确授权,并设置合适的数据保护和删除机制。")
print()

app = App(args)
app.run()


if __name__ == "__main__":
main()
